Implementing KV Cache from Scratch in nanoVLM: A 38% Speedup in Autoregressive Generation

Introduction

Autoregressive language models generate text one token at a time. Each new prediction requires a full forward pass through all transformer layers, leading to redundant computations.

For example, generating the next token in:
[What, is, in,] → [the]
requires recomputing attention over [What, is, in,] even though these tokens haven’t changed.

KV Caching solves this inefficiency by storing and reusing intermediate computations. In this post, we’ll:

Revisit transformer attention mechanics.
Identify where redundancy occurs.
Implement KV Caching in nanoVLM (a minimal VLM built with PyTorch).
Benchmark the speedup (38

Revisiting Transformer Attention

A transformer layer consists of:

Multi-head self-attention
Feed-forward network (MLP)
Residual connections & layer norm

Self-attention computes:

Queries (Q), Keys (K), Values (V) from input embeddings.
Attention scores via softmax(QKᵀ / √dₖ).
Output as a weighted sum of V.

Here’s a minimal PyTorch implementation:



import torch
import torch.nn.functional as F

# Input embeddings (seq_len=5, dim=10)
input_emb = torch.randn(5, 10)

# Project to Q, K, V
Q = input_emb @ W_q
K = input_emb @ W_k
V = input_emb @ W_v

# Causal masking (no peeking ahead)
mask = torch.tril(torch.ones(5, 5))
scores = (Q @ K.T).masked_fill(mask == 0, -torch.inf)
output = F.softmax(scores, dim=-1) @ V

import torch

import torch.nn.functional as F

# Input embeddings (seq_len=5, dim=10)

input_emb = torch.randn(5, 10)

# Project to Q, K, V

Q = input_emb @ W_q

K = input_emb @ W_k

V = input_emb @ W_v

# Causal masking (no peeking ahead)

mask = torch.tril(torch.ones(5, 5))

scores = (Q @ K.T).masked_fill(mask == 0, -torch.inf)

output = F.softmax(scores, dim=-1) @ V

Where Redundancy Creeps In

During autoregressive generation:

The model predicts tᵢ₊₁ given [t₀...tᵢ].
At each step, it recomputes K and V for the entire sequence—even though only the newest token changes.

Example:



new_token_emb = torch.randn(1, 10)
extended_input = torch.cat([input_emb, new_token_emb], dim=0)

# K and V for the first 5 tokens are unchanged!
K_ext = extended_input @ W_k
torch.testing.assert_close(K, K_ext[:5])  # Passes!

new_token_emb = torch.randn(1, 10)

extended_input = torch.cat([input_emb, new_token_emb], dim=0)

# K and V for the first 5 tokens are unchanged!

K_ext = extended_input @ W_k

torch.testing.assert_close(K, K_ext[:5]) # Passes!



Original (5×5):       Extended (6×6):
■ ■ ■ ■ ■            ■ ■ ■ ■ ■ □
■ ■ ■ ■ ■            ■ ■ ■ ■ ■ □
■ ■ ■ ■ ■    →       ■ ■ ■ ■ ■ □
■ ■ ■ ■ ■            ■ ■ ■ ■ ■ □
■ ■ ■ ■ ■            ■ ■ ■ ■ ■ □
                     □ □ □ □ □ □

Original (5×5): Extended (6×6):

■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □

■ ■ ■ ■ ■ → ■ ■ ■ ■ ■ □

■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □

□ □ □ □ □ □

■ = Already computed (reused)
□ = Unnecessary recomputation

How KV Caching Fixes It

Instead of recomputing K and V for the entire sequence:

Cache K and V after the first pass.
For new tokens, compute only the latest Kₙₑᵥ and Vₙₑᵥ.
Concatenate them with the cached values.

Key Insight:

Prefill Phase: Process the full prompt and populate the cache.
Decode Phase: Generate tokens incrementally using cached K/V.

Implementing KV Cache in nanoVLM

We modified three components:

1. Attention Block (`LanguageModelGroupedAttention`)



def forward(self, x, cos, sin, block_kv_cache=None):
    is_prefill = block_kv_cache is None
    q_curr, k_curr, v_curr = project_current_tokens(x)

    if not is_prefill:
        # Append new K/V to cache
        k = torch.cat([block_kv_cache['key'], k_curr], dim=2)
        v = torch.cat([block_kv_cache['value'], v_curr], dim=2)
    else:
        k, v = k_curr, v_curr

    block_kv_cache = {'key': k, 'value': v}
    return attention_output, block_kv_cache

def forward(self, x, cos, sin, block_kv_cache=None):

is_prefill = block_kv_cache is None

q_curr, k_curr, v_curr = project_current_tokens(x)

if not is_prefill:

# Append new K/V to cache

k = torch.cat([block_kv_cache['key'], k_curr], dim=2)

v = torch.cat([block_kv_cache['value'], v_curr], dim=2)

else:

k, v = k_curr, v_curr

block_kv_cache = {'key': k, 'value': v}

return attention_output, block_kv_cache

2. Layer-Wise Cache Tracking (`LanguageModel`)



def forward(self, x, kv_cache=None, start_pos=0):
    for i, block in enumerate(self.blocks):
        x, kv_cache[i] = block(x, cos, sin, kv_cache[i])
    return x, kv_cache

def forward(self, x, kv_cache=None, start_pos=0):

for i, block in enumerate(self.blocks):

x, kv_cache[i] = block(x, cos, sin, kv_cache[i])

return x, kv_cache

3. Two-Phase Generation (`VisionLanguageModel`)



# Prefill: Process prompt and build cache
prompt_out, kv_cache = self.forward(prompt, kv_cache=None, start_pos=0)

# Decode: Generate tokens incrementally
for i in range(max_new_tokens):
    next_token = sample(prompt_out)
    decode_out, kv_cache = self.forward(next_token, kv_cache, start_pos=i)

# Prefill: Process prompt and build cache

prompt_out, kv_cache = self.forward(prompt, kv_cache=None, start_pos=0)

# Decode: Generate tokens incrementally

for i in range(max_new_tokens):

next_token = sample(prompt_out)

decode_out, kv_cache = self.forward(next_token, kv_cache, start_pos=i)

Results & Takeaways

✅ 38 Percent faster generation (benchmarked on nanoVLM).
✅ Memory-efficient (grows linearly with sequence length).
✅ Position-aware (correct rotary embeddings via start_pos).

Trade-offs:

Slightly more complex code.
Restricts some advanced inference methods (e.g., beam search).

Conclusion

KV Caching is a game-changer for autoregressive models. By eliminating redundant computations, it enables faster, longer, and more efficient generation—critical for real-world applications.

Let us know your thoughts in the comments!
